Frequency-Current or Frequency-Voltage Inverter

Dat 4540 Signal transducer can work at heavy condition and is frequency and Puls input. It converts to this signals to 4-20mA, 0-20 mA or 0-10 Volt.There is galvonic isolation between supply, inputs and outputs.Signal configuration can be done from dipswitch and PC.

Technical Documentation

• PDF l Technical Properties
• PDF l User Guide
• PDF l Connection Scheme

Technical Properties

• Input Signal:Tacho, Voltage, TTL, Namur, PNP. See Data sheet for range.

• Signal Output: Current 4-20mA, 0-20mA Min span 4mA. Voltage 0-10V Min Span 1 V.

• Output Contact: 2 X SPDT Max Load 250Vac, 2 Amp.

• Digital Output:Transister Output Max load 30 Vdc, 100mA.

• Supply Voltage: 20 to 30 Vdc. Reverse Polarite Protection 60 Vdc.

• Current Consumption: Current output 90 mA max.

• Working Temperature: Operative- 4°F +158°F - 20°C +70°C

• Storage Temperature: - 40°F +185°F - 40°C +85°C.

• Humidity: (none Condensing) 0-90%.

• Housing: Material Self-extinguishing.

• Dimensions: 3 1/2" x 4 1/2 " x 1/2", 90 x 112x x 12.5 mm.

• Weight: 3 oz 90 g.

• EMC:.For industrial environments.

• Immunity: EN 61000-6-2.

• Emission: EN 61000-6-4.

• Configuration: Configuration with Computer and configurasyon
