Dimens KT800 Recorder

Industrial Recorder KT800 Dimens

Introducing the Dimens KT800R, a powerful 48-channel universal input paperless recorder that sets new standards for data acquisition and analysis.

Specifications:

System:

  • Cutting-edge LSI and components from renowned international manufacturers.
  • High-speed 32-bit ARM microprocessor for simultaneous 48-channel signal detection, recording, display, and alarm.
  • A high-brightness 10.4-inch 800x600 graphic LCD with wide viewing angles.
  • All isolated universal inputs that require no jumpers and are configured through software.
  • New switching power supply operating between 100VAC and 240VAC.
  • Integrated hardware real-time clock for precise timekeeping.
  • 24VDC transmitter isolation distribution.
  • Robust aluminum sealed enclosure and internal shielding for harsh environments.
  • Large-capacity FLASH memory for secure data storage.
  • 12 relay alarm outputs.

Signal:

  • Accepts various standard signals: current, voltage, frequency, millivolt, thermocouple, RTD.
  • Impressive signal full-scale accuracy of ±0.2%.
  • Standard 4-20mA transmitter output.

Software:

  • Secure software password lock for user configuration.
  • Configurable English menu with engineering digit display.
  • Quantity display range from -9999 to 30,000, supporting vacuum operations and scientific notation.
  • Configurable upper and lower channel-specific alarms with storage of the latest 256 alarms.
  • Each channel supports flow accumulation and offers various report formats (daily, monthly, annual).
  • Selectable horizontal or vertical curve display modes.
  • Features a library of 6,500 Chinese characters (GB2312).
  • Utilizes the versatile T6 input method for ease of operation.

Communication:

  • Standard Ethernet interface (RJ45).
  • Standard serial communication interfaces: RS232C and RS485.
  • Supports the Modbus-RTU communication protocol for various data types.
  • Compatible with DataManagement data management software and other specialized configuration software.
  • Dual-card backup with U disk and SD card support.
  • FAT32 file system support for easy data file recognition in Windows.
  • External micro-printer support for data printing.

Elevate your industrial operations with the advanced capabilities of the Dimens KT800R. Experience precision, reliability, and efficiency in one powerful device. Optimize your processes today!
