DAT 3580 MODBUS TCP Converter

Dat 3580 Modbus Tcp Signal Converter

Dat 3580 MTCP Ethernet Gateway allows to RS485 Modbus signal via ethernet on modbus TCP with other modbus devices to communication. A full electrical isolation are available between input and output channels.

Technical Documentation
Technical Properties
  • Brand: Datexel (Made in Italya)
  • Network Interface: Ethernet 10/100Base-T
  • Protocol: Modbus TCP
  • Connection:RJ-45
  • 38400bps: 1,2 km.
  • 19200bps: 2 km.
  • 9600bps: 3 km.
  • 4800bps: 4 km.
  • 2400bps: 5 km.
  • 1200bpsı: 7 km.
  • Number of Moduls: up to 32 pieces
  • Switching Time: M150 uS
  • Supply Voltage: between 18 - 30 Volt
  • Isolation: 1500 Vac Power Supply / Ethernet
    2000 Vac Power Supply / RS485-422
    2000 Vac Ethernet / RS485-422
  • Temperature: - 4°F +145°F - 20°C +60°C
  • Humidity: 0-90%.
  • Switching Time: M150 uS
  • Immunity: EN 61000-6-2.
  • Emission: EN 61000-6-4.
