Dat 3015-I 4-Channel Current Input Analogue Module
The DAT 3015 - 4 Channel Analogue Module is a reliable and versatile solution for acquiring and converting analogue signals into digital data, ensuring high-precision performance in demanding industrial environments. This module supports up to four independent analogue inputs, making it ideal for multi-sensor applications in automation, process control, and monitoring systems.
Key Features:
- Four Independent Analogue Channels: The DAT 3015 allows for the simultaneous monitoring and conversion of four different analogue signals, making it suitable for complex multi-sensor environments.
- High Accuracy: Built with precision in mind, the module ensures accurate signal conversion, maintaining the integrity of critical data.
- Wide Input Range: Compatible with a variety of input signals, including voltage and current, this module offers flexibility across various industrial systems.
- Isolated Inputs and Outputs: The DAT 3015 provides galvanic isolation between inputs, outputs, and power supply, ensuring safe and reliable operation in high-noise environments.
- Durable and Compact Design: Housed in a rugged enclosure, the DAT 3015 is designed for durability in harsh industrial settings while maintaining a compact form factor to save space in control panels.
Applications:
- Process Control Systems: The DAT 3015 is widely used in process control applications where accurate and reliable data acquisition from multiple sensors is critical.
- Automation Systems: Perfect for industrial automation, the module ensures smooth signal conversion for enhanced control and monitoring.
- Energy Monitoring: Track and analyze key energy parameters by converting and processing data from multiple sources using the DAT 3015.
Technical Specifications:
- Input Types: Voltage (±10V, ±5V, ±1V, ±500mV, etc.), Current (±20mA)
- Resolution: 16-bit A/D conversion for high-precision data output
- Operating Temperature: -40°C to +85°C, making it suitable for extreme environments
- Power Supply: 10 - 32Vdc
- Dimensions: Compact size for easy integration into various systems
Benefits of Using the DAT 3015:
- Improved Data Accuracy: With 16-bit resolution, the DAT 3015 guarantees high-quality, accurate data acquisition, which is critical for process optimization and system performance.
- Flexibility Across Applications: Thanks to its compatibility with a range of input signals, the DAT 3015 can be deployed in various industries such as manufacturing, energy, and automation.
- Reliable Performance: The module’s isolated design ensures safe operation even in environments prone to electrical noise, making it dependable for long-term use.
- Easy Installation: Its compact design and straightforward configuration make the DAT 3015 easy to integrate into existing systems, minimizing setup time.
Why Choose RST’s DAT 3015 - 4 Channel Analogue Module?
At RST Measurement Control Instruments, we are committed to providing high-quality, innovative solutions for industrial automation and process control. The DAT 3015 offers superior accuracy, durability, and versatility for businesses looking to optimize their data acquisition and monitoring systems.
With a 2-year warranty, you can trust the DAT 3015 to deliver reliable, long-term performance, even in the most demanding industrial applications.
Technical Documentation
Technical Properties
- Brand: Datexel (Made in Italy)
- Input:
- Current: 4 Channels -20 to 20 mA
- Communication:
- RS485: Modbus RTU Master/Slave.
- RS232: Modbus Slave.
- Supply: Current 10 - 30 Vdc. Reverse Polarity Protection 60 Vdc.
- Maximum Current: 30 mA.
- Working Temperature: Operative Temperature - 4°F +140°F - 20°C +60°C Storage
- Storage Temperature: - 40°F +185°F - 40°C +85°C.
- Humidity: (not condensing) 0-90%.
- Housing: Material self-extinguishing.
- Dimensions: W x L x H 3 3/4X 3 1/2 X 1 7/8 inch, 90 x 74 x 48mm.
- Weight: 7 oz 200 g.
- EMC. For industrial environments.
- Immunity: EN 61000-6-2.
- Emission: EN 61000-6-4.
- Isolation: 1500Vac between Modbus Master, Slave ve Power supply , 50Hz, 1 minute.
- Configuration: PC computer configuration.
