Dat 3017-I 8-Channel Current Input Analogue Module
The DAT 3017 I - 8 Channel Analogue Module is designed to deliver high-precision signal acquisition and conversion for demanding industrial applications. With eight independent analogue input channels, this module is ideal for environments where multiple sensors must be monitored and processed simultaneously. Its robust construction and advanced features make it a reliable solution for industries such as manufacturing, process control, and automation.
Key Features:
- Eight Independent Analogue Inputs: The DAT 3017 I supports up to eight separate input channels, allowing simultaneous measurement from various sensors and devices in your system.
- Wide Input Signal Range: Compatible with a variety of signal types, including voltage and current, offering flexibility across different industrial systems and applications.
- High Accuracy with 16-bit Resolution: Ensures accurate signal conversion and maintains data integrity, critical for optimizing performance in automation and control processes.
- Galvanic Isolation: Each channel is fully isolated from the others, as well as from the power supply, providing protection against electrical noise and interference in harsh industrial environments.
- Rugged and Compact Design: The DAT 3017 I is built to withstand challenging environments with extreme temperatures and high vibration, while its compact design saves valuable space in control panels.
Applications:
- Industrial Automation: Enhance system efficiency by monitoring multiple sensors simultaneously, such as temperature, pressure, or flow sensors, for optimized process control.
- Energy Management Systems: Collect and process data from various energy monitoring devices, helping to improve energy efficiency and system reliability.
- Process Control: Monitor key parameters across multiple stages of production, ensuring accurate, real-time data acquisition for improved quality and system control.
Technical Specifications:
- Input Types: Voltage (±10V, ±5V, ±2.5V, ±1V) and Current (±20mA)
- Resolution: 16-bit for high-precision data output
- Channel Isolation: 1500 Vac for enhanced protection
- Operating Temperature: -40°C to +85°C for extreme environments
- Power Supply: 10 – 30Vdc
- Data Transmission: RS485 Modbus RTU protocol for easy integration with control systems
- Dimensions: Compact size for easy installation
Advantages of the DAT 3017 I - 8 Channel Analogue Module:
- Optimized for Multi-Sensor Environments: With eight channels, the DAT 3017 I is perfect for industrial systems where multiple sensor inputs need to be processed simultaneously.
- Improved System Reliability: The galvanic isolation provides protection against interference and electrical noise, ensuring accurate data in even the most challenging industrial environments.
- Flexible Integration: The module's compatibility with the RS485 Modbus RTU protocol makes it easy to integrate into existing industrial control systems, reducing installation time and costs.
- Durable and Long-Lasting: Designed to withstand harsh conditions, the DAT 3017 I is a reliable choice for long-term industrial use, with a 2-year warranty included for peace of mind.
Why Choose RST’s DAT 3017 I - 8 Channel Analogue Module?
At RST Measurement Control Instruments, we offer cutting-edge solutions to meet the evolving needs of industrial automation and process control systems. The DAT 3017 I provides superior accuracy, versatility, and durability, making it the ideal choice for industries looking to optimize performance through reliable signal acquisition.
Backed by our industry expertise and commitment to quality, the DAT 3017 I delivers exceptional performance in demanding industrial applications, ensuring the highest standards of precision and durability.
Technical Documentation
Technical Properties
- Brand: Datexel (Made in Italy)
- Input:
- Current: 8 Channels-20 to 20 mA
- Communication:
- RS485: Modbus RTU Master/Slave.
- RS232: Modbus Slave.
- Supply: Current 10 - 30 Vdc. Reverse Polarity Protection 60 Vdc.
- Maximum Current: 30 mA.
- Working Temperature: Operative Temperature - 4°F +140°F - 20°C +60°C Storage
- Storage Temperature: - 40°F +185°F - 40°C +85°C.
- Humidity: (not condensing) 0-90%.
- Housing: Material self-extinguishing.
- Dimensions: W x L x H 3 3/4X 3 1/2 X 1 7/8 inch, 90 x 74 x 48mm.
- Weight: 7 oz 200 g.
- EMC. For industrial environments.
- Immunity: EN 61000-6-2.
- Emission: EN 61000-6-4.
- Isolation: 1500Vac between Modbus Master, Slave ve Power supply, 50Hz, 1 minute.
- Configuration: PC
