Programmable Graphic LCD DAT9550

The DAT 9550 is a sleek graphic display meant for panel installation. It effortlessly communicates using Modbus RTU protocol over RS-485 and RS-232, serving as a Serial Slave. It also boasts an RS-485 Master port to interact with connected Modbus Slave devices. Whether it's for visualizing data from DAT9000 series Intelligent Units, a PC, PLC, or a panel operator, the DAT 9550 offers versatile solutions.

Technıcal Properties:

  • Brand: DATEXEL ( (Italy))
  • Code: DAT9550
  • Digital Display: 132 X 32 Pixels.
  • Information:
    RS485: Port 1 Modbus RTU Master, Port 0 Modbus RTU Slave.
    RS232: Modbus RTU Slave.
  • Ethernet: Ethernet 10Base-T, Modbus TCP.
  • Supply Voltage:Voltage 10 - 30 Vdc. Reverse Polarity Protection 60 Vdc.
  • Operating Temperature: Operative Temperature - 4°F +140°F - 20°C +60°C Storage
  • Storage Temperature: - 40°F +185°F - 40°C +85°C.
  • Humidity: (no condensing) 0-90%.
  • Housing: Material self-extinguishing.
  • Dimensions: W x L x H 4 x 4 3/4 x 1inch, 100 x 120 x 22.5mm.
  • Weight: 7oz 200g.
    EMC. For industrial environments.
  • Immunity: EN 61000-6-2.
  • Emission: EN 61000-6-4.
  • Isolation: 1500Vac, 50Hz, 1 Minute.
  • Configuration: PC Configurable, DIP Switches.r
