Unlock Precise Control with the Dimens 6501P pH/Redox Controller
Dimens 6501P Controller: Your Solution for Water Treatment and Industrial Control
Application:
- Ideal for Process Water, Disinfection, Drinking Water, Food & Beverage, Cooling Water, Wastewater Treatment, and Pool industries.
Features and Technical Data:
Measurement Parameters:
- pH: -2.00 to 16.00 pH
- ORP: -2000 to 2000 mV
- Temperature: -10 to 120℃
Input:
- Measuring Sensor: Dimens pH/ORP sensor
- Temperature Probe: Pt-1000
Output:
- Analog Output 1: Isolated 4-20 mA current output for pH/ORP, fully customizable.
- Relay 1 & 2 Outputs: ON/OFF operation, selectable action (High/Low), adjustable set points, and hysteresis.
General Information:
- Power Supply: 90 - 260V AC, 50/60Hz; 24VDC (Optional)
- Operating Temperature: 0 - 60℃
- Storage Temperature: -20 - 70℃
- Humidity: Max. 90% rH at 40℃ (non-condensing)
- LCD Screen: Large crystal display with white backlight
- Passcode: Set mode - 0022
- Protection Grade: IP65
- Dimensions: 96 x 96 x 140mm
- Installation: Pipe/Panel Mounting
- Panel Cut Size: 90 x 90mm
- Weight: 0.5 Kg
Enhance your water treatment and industrial processes with precision and control
