1-Wire Carbon Dioxide Sensor TSM400-1-CP

Carbon Dioxide Sensor | Digital Sensing Element 1-Wire TSM400

Carbon dioxide, often denoted as CO2, is a colorless gas vital to Earth's atmosphere. The TSM400-1-CP is a versatile sensor compatible with the 1-Wire protocol, designed to measure carbon dioxide concentration and atmospheric pressure. Both fundamental sensor components for CO2 and pressure are digital, ensuring precise measurements and long-term stability.

The atmospheric pressure sensing element comes factory calibrated, eliminating the need for lifetime recalibration. Self-calibration is available for carbon dioxide measurements, triggered when the sensor is exposed to fresh air containing around 400 ppm CO2.

The TSH400-1-CP is housed within a slim plastic enclosure with a suitable bottom part for mounting on standard flush-mounted or cavity wall boxes (ø68mm, with installation openings at 61mm).

Elevated carbon dioxide levels can lead to reduced productivity, increased blood pressure, headaches, and even life-threatening conditions in high concentrations. Therefore, monitoring and controlling carbon dioxide levels are crucial for offices, workplaces, schools, and public buildings.

Features:

  • LED indicator for communication status
  • Exceptional long-term stability
  • Self-calibration for carbon dioxide measurements in fresh air
  • Firmware updates via the interface
  • Low current consumption
  • Unique 64-bit serial numbers for multi-sensor compatibility

Applications:

  • Environmental quality assessment in office spaces
  • Monitoring carbon dioxide pollution
  • Indoor air quality systems
  • Safety industries

This 1-Wire carbon dioxide sensor is compatible with the following devices:

  • Temperature and humidity data logger TCW210-TH
  • Ethernet IO module TCW241
  • Ethernet data logger TCW220
  • 4G LTE universal IO module TCG140-4

Technical Properties:

  • Physical characteristics
  • Dimensions: 81 x 81 x 30 mm
  • Weight: 66 g
  • Environmental limits
  • Operating temperature range: -20 to 60°C
  • Operating relative humidity range: 5 to 95% (non-condensing)
  • Storage temperature range: -20 to 60°C
  • Storage relative humidity range: 5 to 95% (non-condensing)
  • Ingress protection: IP20
  • Power requirements
  • Operating voltage range (including -15/+20% according to IEC 62368-1): 4.5 to 26 VDC
  • Current consumption: 25 mA@5VDC (Peak: 150 mA@5VDC)
  • CO2 measurements
  • Range: 400 to 5000 ppm
  • Accuracy: ± (40 ppm + 5 %)
  • Resolution: 1 ppm
  • Calibration: Manual
  • Pressure measurements
  • Range: 10 to 1200 hPa
  • Accuracy (min): ±1.5 (25°C, 750 hPa)
  • Accuracy (max): ±2.5 (-20°C to + 85°C, 300 to 1100 hPa)
  • Resolution: 1 hPa
  • Warranty
  • Warranty period: 3 years
