Dipping Type Electromagnetic Flowmeter (Indicator)

Electromagnetic flowmeters are one of the most preferred products in flow measurement with conditions that are conductive of the fluid. It is preferred in many areas due to the fact that there are no moving parts in the flow tube or flow system. Dripping Type Electromagnetic Flowmeter shows excellent performance because the wet parts and measurement electrodes can be selected from materials that cannot be corroded by the fluid therefore the pressure loss is zero.

Application Areas

• Treatment Plants
• Chemical, Petrochemical Sector
• Food Sector
• Textile Sector
• Paper Production Sector
• Plants
• Water Distribution Network

Technical Documentation

• PDF l Technical Properties
• PDF l User Guide
• PDF l Connection Scheme

Technical Properties

• Connection Diameter: DN15……DN600

• Measurement Range (Speed): 0,15m/s……..8 m/s
• Lineerity: +/- 1 %
• Repeatability: 0,5 % O.D
• Pressure: 16 Bar most
• Temperature: -10…..+60C, PEEK For Body -10…+150C
• Wet Parts:AISI316L / PVDF, AISI316L / PEEK,
• Fluid: Conductive Liquid ≥20 μS/cm
• Protection Class: IP 65
• Electrode: 316 L
• Supply Voltage: 12 – 24 Volt DC
• Output Signal: 4-20mA, Puls + 2 contact
• Display: LCD Display over showing instantaneous and total value
