AAlborg ZFM Digital Mass Gas Flow Meter
ZFM is a state-of-the-art intelligent digital Mass Flow Meter. Fluid Surface Contact material is offered in aluminum or stainless steel versions.
With the free ZFM configuration software, the user can program the gas type and flow range he wants to use in a few minutes without removing the product.
These meters provide low cost and savings due to the ability to measure multiple applications and gases.
- It has Multi-Gas / Multiple Flow Range and Resistance Pressure Feature up to 8 Bar.
- High Sensitivity 0.5% RD, 0.2% FS
- 46 Different engineering units can be selected
- Different gases can be measured with K conversion Factor of up to 26 gases
- Self-diagnostic feature thanks to status LED or O LED display
- User selectable analog output option
- Stores additional calibration data for up to 10 gases
Technical Properties
- Marka / Model: Aalborg / ZFM17, ZFM37, ZFM47
- Analog Çıkış: 4 - 2mA, 0 - 5 VDC, 0 - 10Vdc
- Dijital Çıkış: RS485, RS232 Opsiyoneldir
- Hassasiyet: 0.5 % RD, 0.2 % FS
- Örnekleme Zamanı: 01 sn. F.S %2 ila %100'ünün üzerinde gerçek akış hızının ±%2'si dahilinde
- Ortam sıcaklığı: 0….50°C
- Ölçüm Gazları: 10 Adet Kalibrasyonlu 26 farklı gaza kadar seçebilme özelliği
- Besleme Gerilimi: 12 Vdc 15Vdc veya 24 Vdc
- Akışkan Temas Yüzey Malzemesi: Alüminyum, 316L pas. Çelik
- Çalışma sıcaklığı: -10…50°C
- Gösterge: 128X64 Grafik LCD veya O LED ekran
- Basınç: 1000 PSI
- Ölçüm Aralığı: 0 - 10 l/dk ila 0-100 L/dk
- Hat Çapı: 1/4" - 3/8" Fittings
- O-Ring: Buna-N, Viton EPR PTFE / Kalrez
