Density - Viscosity - Viscosity Meter

Coriolis Flowmeter, What Is It? How Does It Work? Prices

  • Measure density, concentration, gravity, temperature of liquid
  • Density, concentration, specific gravity and temperature of the liquid meter
  • The measurement accuracy of the product depends on pressure, density viscosity, etc. is not affected by these factors.
  • Accuracy: ±0.002g/cc; (±0.001g/cc optional)
  • Pipeline interface detection, mineral solid slurry monitoring, control of corrosive acid concentrates
  • It can be used wherever concentration, intensity, etc. need to be quickly monitored and controlled.
  • It is the perfect solution for measuring density, viscosity and temperature online in pipelines, tanks or pools.
  • It is suitable with corrosive and different chemicals.
  • A wide range of corrosion resistant sensors for measuring density and concentration of critical chemicals choose from ingredients
  • You can connect the device to DCS, PLC or computer with different communication protocols.

Technical Properties

  • Type: DMS-1-CR
  • Density Accuracy: ±2.0 kg/m3 (± 0.002g/cm3; ±1.0 kg/m3 (±0.001g/cm3 optional)
  • Working density range: 500 - 2500 kg/m3 (0.5 - 2.5 g/cm3)
  • Operating temperature range: -50…+200C at short probe
  • Operating temperature range: -50…+150C on long probe
  • Wet parts: 316 passes. Steel, Alloy C276, PFA Coated 316 rust. Steel, PFA Coated C276
  • Display: Density + Temperature
  • Probe Length: 128 mm, Ask for special length
  • Protection Class: IP67
  • Supply: 24 VDC
  • Analog Output: 4-20mA,
  • Frequency Output: 0-1 KHz.
  • Communication: Modbus RS485, (HART optional)
  • Certificates: CE, ATEX, ISO19001, ISO14001,OHSAS18001
